RISC Computing Platforms

Compatible I/O Expansion Boards

UIO-4030

1 x RS-485

1 x RS-232

1 x 4 DIs & 4 DOs

Specifications

General

USB

–

RS-232

1 x 2 wires RS-232

RS-485

1 x RS-485

GPIO

4 DIs, 4 DOs (2.5~24V)

CAN Bus

–

GbE

–

Dimension

146 x 31 x 22 mm

Environment

Weight

180g

Operating Humidity

5 ~ 95% relative humidity,

non-condensing

Operating Temperature -40 ~ 85 °C

Storage Temperature

-40 ~ 85 °C and 60 °C @ 95% RH

Non-Condensing

Ordering Information

P/N

Description

UIO-4030

UIO-4030, 1 RS232, 4 DIs, 4 DOs,

1 RS-485

Specifications

General

USB

2 x USB 2.0

RS-232

2 x 2 wires RS-232

RS-485

–

GPIO

–

CAN Bus

–

GbE

1 x GbE

Dimension

146 x 31 x 22 mm

Environment

Weight

200g

Operating Humidity

5 ~ 95% relative humidity,

non-condensing

Operating Temperature -40 ~ 85 °C

Storage Temperature

-40 ~ 85 °C and 60 °C @ 95% RH

Non-Condensing

Ordering Information

P/N

Description

UIO-4032

UIO-4032, 1 GbE, 2 USB, 2 RS-232

Specifications

General

USB

–

RS-232

2 x 2 wires RS-232

RS-485

–

GPIO

–

CAN Bus

1 x CAN bus 2.0B, 1 Mbps

GbE

–

Dimension

146 x 31 x 22 mm

Environment

Weight

180g

Operating Humidity

5 ~ 95% relative humidity,

non-condensing

Operating Temperature -40 ~ 85 °C

Storage Temperature

-40 ~ 85 °C and 60 °C @ 95% RH

Non-Condensing

Ordering Information

P/N

Description

UIO-4034

UIO-4034, 1 CAN, 2 RS-232

UIO-4032

1 x GbE

2 x USB2.0

2 x RS-232

UIO-4034

1 x CAN bus

2 x RS-232
