Data Sheet
ADAR2001
Rev. 0 | Page 33 of 39
Addr Name
Bits Bit Name
Description
Reset Access
0x065 TX_EN2_MODE_10
[7:3] RESERVED
Reserved
0x0
R
2
SPLT1_EN_MD10
Transmit Mode 10 Active Splitter 1 Enable
0x1
R/W
1
SPLT12_EN_MD10
Transmit Mode 10 Channel 1 to Channel 2 Active
Splitter Enable
0x1
R/W
0
SPLT34_EN_MD10
Transmit Mode 10 Channel 3 to Channel 4 Active
Splitter Enable
0x1
R/W
0x066 TX_EN1_MODE_11
7
CH1_RDY_MD11
Transmit Mode 11 Channel 1 Ready Enable
0x1
R/W
6
CH1_ACT_MD11
Transmit Mode 11 Channel 1 Active Enable
0x0
R/W
5
CH2_RDY_MD11
Transmit Mode 11 Channel 2 Ready Enable
0x1
R/W
4
CH2_ACT_MD11
Transmit Mode 11 Channel 2 Active Enable
0x1
R/W
3
CH3_RDY_MD11
Transmit Mode 11 Channel 3 Ready Enable
0x1
R/W
2
CH3_ACT_MD11
Transmit Mode 11 Channel 3 Active Enable
0x0
R/W
1
CH4_RDY_MD11
Transmit Mode 11 Channel 4 Ready Enable
0x1
R/W
0
CH4_ACT_MD11
Transmit Mode 11 Channel 4 Active Enable
0x1
R/W
0x067 TX_EN2_MODE_11
[7:3] RESERVED
Reserved
0x0
R
2
SPLT1_EN_MD11
Transmit Mode 11 Active Splitter 1 Enable
0x1
R/W
1
SPLT12_EN_MD11
Transmit Mode 11 Channel 1 to Channel 2 Active
Splitter Enable
0x1
R/W
0
SPLT34_EN_MD11
Transmit Mode 11 Channel 3 to Channel 4 Active
Splitter Enable
0x1
R/W
0x068 TX_EN1_MODE_12
7
CH1_RDY_MD12
Transmit Mode 12 Channel 1 Ready Enable
0x1
R/W
6
CH1_ACT_MD12
Transmit Mode 12 Channel 1 Active Enable
0x0
R/W
5
CH2_RDY_MD12
Transmit Mode 12 Channel 2 Ready Enable
0x1
R/W
4
CH2_ACT_MD12
Transmit Mode 12 Channel 2 Active Enable
0x0
R/W
3
CH3_RDY_MD12
Transmit Mode 12 Channel 3 Ready Enable
0x1
R/W
2
CH3_ACT_MD12
Transmit Mode 12 Channel 3 Active Enable
0x1
R/W
1
CH4_RDY_MD12
Transmit Mode 12 Channel 4 Ready Enable
0x1
R/W
0
CH4_ACT_MD12
Transmit Mode 12 Channel 4 Active Enable
0x1
R/W
0x069 TX_EN2_MODE_12
[7:3] RESERVED
Reserved
0x0
R
2
SPLT1_EN_MD12
Transmit Mode 12 Active Splitter 1 Enable
0x1
R/W
1
SPLT12_EN_MD12
Transmit Mode 12 Channel 1 to Channel 2 Active
Splitter Enable
0x1
R/W
0
SPLT34_EN_MD12
Transmit Mode 12 Channel 3 to Channel 4 Active
Splitter Enable
0x1
R/W
0x06A TX_EN1_MODE_13
7
CH1_RDY_MD13
Transmit Mode 13 Channel 1 Ready Enable
0x1
R/W
6
CH1_ACT_MD13
Transmit Mode 13 Channel 1 Active Enable
0x1
R/W
5
CH2_RDY_MD13
Transmit Mode 13 Channel 2 Ready Enable
0x1
R/W
4
CH2_ACT_MD13
Transmit Mode 13 Channel 2 Active Enable
0x1
R/W
3
CH3_RDY_MD13
Transmit Mode 13 Channel 3 Ready Enable
0x1
R/W
2
CH3_ACT_MD13
Transmit Mode 13 Channel 3 Active Enable
0x1
R/W
1
CH4_RDY_MD13
Transmit Mode 13 Channel 4 Ready Enable
0x1
R/W
0
CH4_ACT_MD13
Transmit Mode 13 Channel 4 Active Enable
0x0
R/W
0x06B TX_EN2_MODE_13
[7:3] RESERVED
Reserved
0x0
R
2
SPLT1_EN_MD13
Transmit Mode 13 Active Splitter 1 Enable
0x1
R/W
1
SPLT12_EN_MD13
Transmit Mode 13 Channel 1 to Channel 2 Active
Splitter Enable
0x1
R/W
0
SPLT34_EN_MD13
Transmit Mode 13 Channel 3 to Channel 4 Active
Splitter Enable
0x1
R/W
