35 / 241 page  Rev 1.3 35 6. System Modules System modules encompass power domains, resets, clocks, system timers, power management, and encryption. Figure 6.1 shows these modules and how they interact. Figure 6.1. System Module Block Diagram nRESET VDD_PADS VREG_OUT VDD_CORE VDD_MEM POR HV POR LVcore POR LVmem VREG_1V8 VREG_1V25 always-on supply mem supply core supply POR LV POR HV Reset Filter External Regulator optional connections for external regulator OSCRC OSC32K DIV10 CLK1K CLK32K OSC32A OSC32B JRST always-on domain mem domain ARM® Cortex -M3 Debug AHB-AP core domain ARM® Cortex -M3 CPU FLITF Flash RAM OSC24M OSCHF OSCA OSCB SYSCLK CDBGRSTREQ Power Management Watchdog Sleep Timer watchdog deep sleep wakeup REG_EN recomended connections for internal regulator PRESETHV PRESETLV registers registers Security Accelerator SWJ Wakeup Recording always-on supply mem supply JTAG-TAP |
|
