Surface Mount Multilayer Ceramic Chip Capacitors (SMD MLCCs)

HV-HT Series, High Voltage, High Temperature 200°C, C0G Dielectric, 500 – 2,000 VDC (Industrial Grade)

Waffle Tray Packaging Information – 2" x 2" w/ Static Protection

Figure 9 – Waffle Tray Dimensions – Inches (Millimeters)

90°

A

0.10 (2.54) X 45°

1.800 ±0.004 SQ

(45.720 ±0.102 SQ)

1.812 ±0.004 SQ

(46.025 ±0.102 SQ)

2.000 ±0.004 SQ

(50.800 ±0.102 SQ)

STANDARD RIB MATRIX

X

M2

M

M3

M1

Y

X

Z

0.086

(2.184)

0.156 +0.002/-0.003

(3.962 +0.051/-0.076)

0.004

(0.102)

0.098

(2.489)
