4 / 30 page  ML6461 4 ELECTRICAL CHARACTERISTICS Unless otherwise specified, AVCC = DVCC = 4.5V to 5.5V, TA = Operating Temperature Range (Note 1) SYMBOL PARAMETER CONDITIONS MIN TYP MAX UNITS POWER PERFORMANCE Power Dissipation 750 mW SUPPLIES AVCC Analog Supply Voltage 4.5 5.5 V DVCC Digital Supply Current 4.5 5.5 V ISA Analog Supply Current 125 mA ISD Digital Supply Current Max. Programmed Clock Rates 35 mA DIGITAL INPUT SIGNALS VIL Input Low Voltage 0.8 V VIH Input High Voltage 2.0 V IIL Low Level Input Current VIN = at 0.1V 1 µA IIH High Level Input Current VIN = at DVCC – 0.1V 1 µA Input Capacitance 2pF DIGITAL OUTPUT SIGNALS VOL Low Level Output Voltage IOUT = 2mA 0.4 V VOH High Level Output Voltage IOUT = 100µA VCC-0.4 V Output Capacitance 50 pF ENCODER AND DAC (Note 2) Output Amplitude Accuracy SMPTE Color Bars 2 5 % CV Output Amplitude SMPTE Color Bars, Peak-to-Peak 0.95 1.05 V C Output Amplitude SMPTE Color Bars, Peak-to-Peak 0.594 0.657 V Y Analog/Digital Bandlimit Swept Multiburst 5.7 MHz C Analog/Digital Bandlimit Swept Multiburst 1.5 MHz Vector Phase Accuracy (Note 3) Swept Multiburst –2.5 1 2.5 º Vector Amplitude Accuracy (Note 3) SMPTE Color Bars –2.5 2.5 % Chroma Phase Linearity NTC7 Stepped Subcarrier –2 2 º Chroma Amplitude Linearity NTC7 Stepped Subcarrier –1 1 IRE Differential Gain NTC7 Modulated Staircase (Note 2) 0.5 1 % Differential Phase NTC7 Modulated Staircase (Note 2) 0.5 1 º ABSOLUTE MAXIMUM RATINGS Absolute maximum ratings are those values beyond which the device could be permanently damaged. Absolute maximum ratings are stress ratings only and functional device operation is not implied. AVCC, DVCC .................................................... –0.3 to 7V Analog and Digital Inputs/Outputs .... –0.3 to AVCC + 0.3V Input current per pin ................................... –25 to 25mA Storage Temperature .................................... –65 to 150ºC Junction Temperature .............................................. 120ºC OPERATING CONDITIONS Temperature Range ........................................ 0°C to 70°C Operating Supply Range ............................... 4.5V to 5.5V |
|
