TVS DIODE FOR ESD PROTECTION

www.unisonic.com.tw

1 of 3

Copyright © 2015 Unisonic Technologies Co., Ltd

QW-R601-073.C

SURFACE MOUNT SILICON

ZENER DIODE



DESCRIPTION

The UTC SMAXXV is a single line TVS diode, for ESD

protection.

The UTC SMAXXV is protection in portable electronics

applications.



FEATURES

* 50 Watts peak pulse power (tp=8/20μs)

* Transient protection for data lines to

ESD=8KV (Contact)

EFT=40A (tp=5/50ns)

Lightning=5A (tp=8/20μs)

* Small package for use in portable electronics.

* Suitable replacement for Multi-Layer Varistors in ESD protection

applications.

* Protects on I/O or power line.

* Low clamping voltage.

* Low leakage current.



SYMBOL

SOD-523

SOD-323

SOD-123

1

2

1

2

1

2



ORDERING INFORMATION

Pin Assignment

Ordering Number

Package

1

2

Packing

SMAXXG-CA2-R

SOD-123

A

K

Tape Reel

SMAXXG-CB2-R

SOD-323

A

K

Tape Reel

SMAXXG-CC2-R

SOD-523

A

K

Tape Reel

Note: Pin Assignment: A: Anode

K: Cathode



MARKING
