NJM431
- 3 -
Ver.2003-07-18
■ TEST CIRCUITS
1. VKA = VREF
2. VKA > VREF
3. IOFF
VO = VKA = VREF
VO = VKA = VREF·
 +
R2
R1
1
+ IREF·R1
(Fig. 1)
(Fig. 2)
(Fig. 3)
■ TYPICAL APPLICATION
(1) Shunt Regulator
(2) Series Regulator
(3) Output Control of a Three-Terminal
fixed Regulator
(4) Constant Current Source
■ POWER DISSIPATION VS. AMBIENT TEMPERATURE
