BAT54TS
Preliminary
DIODE
UNISONICTECHNOLOGIESCO.,LTD
2 of 3
www.unisonic.com.tw
QW-R601-068.b
ABSOLUTE MAXIMUM RATINGS
(TA=25°C, unless otherwise specified. Fore capacitive load, derate current by 20%)
PARAMETER
SYMBOL
RATINGS
UNIT
Peak Repetitive Reverse Voltage
VRRM
30
V
Continuous Forward Current
IF
0.2
A
Peak Forward Surge Current, 1.0s Single Half Sine-Wave
Superimposed on Rated Load (JEDEC Method)
IFSM
0.6
A
Junction Capacitance (VR=1V)
CJ
10
pF
Storage Temperature
TSTG
-55~+150
°C
Operating Junction Temperature
TJ
-55~+150
°C
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
THERMAL CHARACTERISTICS
PARAMETER
SYMBOL
RATINGS
UNIT
Junction to Ambient
θJA
667
°C/W
ELECTRICAL CHARACTERISTICS
(TA=25°C, unless otherwise specified. Fore capacitive load, derate current by 20%)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN TYP MAX UNIT
Maximum Instantaneous Forward Voltage
VF
IF = 0.1mA
0.24
V
IF = 1mA
0.32
V
IF = 10mA
0.4
V
IF = 30mA
0.5
V
IF = 100mA
0.8
V
DC Reverse Current at Rated DC Blocking Voltage
IR
VR = 25V
2
μA
