AD8044

100 s

500mV

0.211V

VS = +5V

RL = 150 TO +2.5V

CL = 5pF

G = –1

4.656V

2.5V

Figure 28a. Output Swing vs. Load Reference Voltage,

VS = +5 V, G = –1

2.5V

100 s

500mV

VS = +5V

RL = 150 TO GND

CL = 5pF

G = –1

4.309V

+10mV

Figure 28b. Output Swing vs. Load Reference Voltage,

VS = +5 V, G = –1

4.5V

3.5V

2.5V

1.5V

0.5V

20ns

500mV

VS = +5V

G = +2

RL = 2k

VIN = 1V p-p

CL = 5pF

Figure 29. One Volt Step Response, VS = +5 V, G = +2

2.6V

2.55V

2.5V

2.45V

2.4V

VS = +5V

G = +1

RL = 2k

CL = 5pF

40ns

50mV

Figure 30. 100 mV Step Response, VS = +5 V, G = +1

2.5V

1.5V

0.5V

200 s

500mV

VIN = 3V p-p

RL = 2k

CL = 5pF

VS = +3V

G = –1

+22mV

+2.920V

Figure 31. Output Swing, VS = +3 V

1.56V

1.52V

1.48V

1.44V

1.40V

1.42V

1.46V

1.50V

1.54V

20ns

20mV

VIN = 0.1V p-p

RL = 2k

CL = 5pF

VS = +3V

G = +1

1.58V

1.60V

Figure 32. Step Response, G = +1, VIN = 100 mV

–10–

REV. B
