37 / 46 page

- 37 -

JANURARY 18, 2013 | DATA SHEET | Rev 3.5

IR3898

6A Highly Integrated SupIRBuck

Single-Input Voltage, Synchronous Buck Regulator

PD-97662

TYPICAL OPERATING WAVEFORMS

Vin = 12V, Vo = 1.2V, Iout = 0-6A Room Temperature, No Air Flow

Figure 32: Start up at 6A Load,

Figure 33: Start up at 6A Load,

Ch1:Vin, Ch2:Vo, Ch3:PGood, Ch4:Enable

Ch1:Vin, Ch2:Vo, Ch3:Vcc, Ch4:PGood

Figure 34: Start up with 1V pre bias

Figure 35: Output Voltage Ripple

0A Load

Ch2:Vo

6A Load

Ch2:Vo

Figure 36: Inductor node at 6A Load, Ch3:LX

Figure 37: Short circuit Recovery

Ch2:Vout,Ch4:Iout(2A/Div)
