ADP196

Data Sheet

Rev. 0 | Page 4 of 12

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

VIN to GND

−0.3 V to +6.5 V

VOUT to GND

EN to GND

−0.3 V to +6.5 V

Continuous Drain Current

±4 A

±2.22 A

Continuous Diode Current

−50 mA

Storage Temperature Range

−65°C to +150°C

Operating Junction Temperature Range

−40°C to +105°C

Soldering Conditions

JEDEC J-STD-020

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

Package Type

Unit

6-Ball WLCSP

260

58

°C/W

6-Lead LFCSP

68.9

44.1

°C/W

ESD CAUTION
