AD8274

Rev. C | Page 3 of 16

SPECIFICATIONS

VS = ±15 V, VREF = 0 V, TA = 25°C, RL = 2 kΩ, unless otherwise noted.

Table 2.

G = ½

G = 2

Parameter

Conditions

Min

Typ

Max

Min

Typ

Max

Unit

DYNAMIC PERFORMANCE

Bandwidth

MHz

Slew Rate

V/μs

Settling Time to 0.1%

10 V step on output,

CL = 100 pF

650

750

675

775

Settling Time to 0.01%

10 V step on output,

CL = 100 pF

725

800

750

825

NOISE/DISTORTION1

THD + Noise

f = 1 kHz,

VOUT = 10 V p-p,

600 Ω load

0.00025

0.00035

Noise Floor, RTO2

20 kHz BW

−106

−100

dBu

Output Voltage Noise

(Referred to Output)

f = 20 Hz to 20 kHz

3.5

μV rms

f = 1 kHz

nV/√Hz

GAIN

Gain Error

0.03

Gain Drift

−40°C to +85°C

0.5

ppm/°C

Gain Nonlinearity

VOUT = 10 V p-p,

600 Ω load

ppm

INPUT CHARACTERISTICS

Offset3

Referred to output

150

700

300

1100

μV

vs. Temperature

−40°C to +85°C

μV/°C

vs. Power Supply

VS = ±2.5 V to ±18 V

μV/V

Common-Mode Rejection

Ratio

VCM = ±40 V,

RS = 0 Ω,

referred to input

Input Voltage Range4

3(−VS + 1.5)

3(+VS − 1.5)

1.5(−VS + 1.5)

1.5(+VS – 1.5)

Impedance5

Differential

VCM = 0 V

kΩ

Common Mode6

kΩ

OUTPUT CHARACTERISTICS

Output Swing

−VS + 1.5

+VS − 1.5

−VS + 1.5

+VS − 1.5

Short-Circuit Current Limit

Sourcing

Sinking

Capacitive Load Drive

200

1200

POWER SUPPLY

Supply Current (per

Amplifier)

2.3

2.6

2.3

2.6

TEMPERATURE RANGE

Specified Performance

−40

+85

−40

+85

°C

1 Includes amplifier voltage and current noise, as well as noise of internal resistors.

2 dBu = 20 log(V rms/0.7746).

3 Includes input bias and offset current errors.

4 May also be limited by absolute maximum input voltage or by the output swing. See the Absolute Maximum Ratings section and Figure 8 through Figure 11 for details.

5 Internal resistors are trimmed to be ratio matched but to have ±20% absolute accuracy.

6 Common mode is calculated by looking into both inputs. The common-mode impedance at only one input is 18 kΩ.
