ADL5243

Data Sheet

Rev. A | Page 8 of 32

Parameter

Conditions

Min

Typ

Max

Unit

LOOP FREQUENCY = 2140 MHz

AMP1 – DSA – AMP2, DSA at minimum attenuation

Gain

31.3

vs. Frequency

±30 MHz

±0.03

Gain Range

Between maximum and minimum attenuation states

32.5

Input Return Loss

S11

−9.3

Output Return Loss

S22

−5.4

Output 1 dB Compression Point

25.3

dBm

Output Third-Order Intercept

∆f = 1 MHz, POUT = 5 dBm/tone

40.0

dBm

Noise Figure

3.1

LOOP FREQUENCY = 2630 MHz

AMP1 – DSA – AMP2, DSA at minimum attenuation

Gain

29.5

vs. Frequency

±60 MHz

±0.56

Gain Range

Between maximum and minimum attenuation states

30.0

Input Return Loss

S11

−12.6

Output Return Loss

S22

−5.8

Output 1 dB Compression Point

24.6

dBm

Output Third-Order Intercept

∆f = 1 MHz, POUT = 5 dBm/tone

39.3

dBm

Noise Figure

3.1

POWER SUPPLIES

Voltage

4.75

5.0

5.25

Supply Current

AMP1

120

AMP2

120

DSA

0.5
