CY25404

Document #: 001-43258 Rev. *C

Page 5 of 13

Absolute Maximum Conditions

Parameter

Description

Condition

Min

Max

Unit

VDD

Supply voltage

–

–0.5

4.5

VDD_CLK_BX

Output bank supply voltage

–

–0.5

4.5

VIN

Input voltage

Relative to VSS

–0.5

VDD+0.5

Temperature, storage

Non functional

–65

+150

°C

ESDHBM

ESD protection (human body model)

JEDEC EIA/JESD22-A114-E

2000

volts

UL-94

Flammability rating

V-0 at 1/8 in.

–

ppm

MSL

Moisture sensitivity level

–

Recommended Operating Conditions

Parameter

Description

Min

Typ

Max

Unit

VDD

VDD operating voltage

2.25

–

3.60

VDD_CLK_BX

Output driver voltage for Bank 1, 2 and 3

2.25

–

3.60

TAC

Commercial ambient temperature

–

+70

°C

TAI

Industrial ambient temperature

–40

+85

°C

CLOAD

Maximum load capacitance

–

tPU

Power-up time for all VDD to reach minimum specified voltage (power ramps must

be monotonic)

0.05

–

500

Notes

1. Guaranteed by design but not 100% tested.

2. Configuration dependent.
