ADSP-BF506F EZ-KIT Lite Evaluation System Manual
2-13
ADSP-BF506F EZ-KIT Lite Hardware Reference
ADC Voltage Reference (JP6)
The ADC voltage reference jumper (JP6) is used to supply a reference
voltage to the ADC. In order to use an external voltage reference, a jumper
must be placed on positions 1 and 2 of JP2. To use the on-board AD780
precision voltage reference, install a jumpers at position 1, 2 and 3, 4. To
supply your own voltage reference, remove all jumpers from JP6 and con-
nect your voltage reference to pins 1 and 3. By default, no jumpers are
installed on JP6.
