ADSP-BF506F EZ-KIT Lite Evaluation System Manual

1-11

Using ADSP-BF506F EZ-KIT Lite

For more information about emulators, contact Analog Devices or go to:

http://www.analog.com/en/embedded-processing-dsp/Blackfin/pro-

cessors/Blackfin_development_tools/fca.html

Expansion Interface II

The expansion interface II allows an Analog Devices EZ-Extender or a

custom-design daughter board to be tested across various hardware plat-

forms that have the same expansion interface.

The expansion interface II implemented on the ADSP-BF506F EZ-KIT

Lite consists of three connectors, which are 0.1 in. shrouded headers (P2–

). The connectors contain a majority of the ADSP-BF506F processor’s

signals. For pinout information, go to “ADSP-BF506F EZ-KIT Lite Sche-

matic” on page B-1. The mechanical dimensions of the expansion

connectors can be obtained by contacting “Technical or Customer

Support”.

For more information about daughter boards, visit the Analog Devices

Web site at:

http://www.analog.com/en/embedded-processing-dsp/Blackfin/pro-

cessors/Blackfin_development_tools/fca.html

Limits to current and interface speed must be taken into consideration

when using the expansion interface. Current for the expansion interface II

is sourced from the EZ-KIT Lite; therefore, the current should be limited

to 1A for 5V and 500 mA for the 3.3V planes. If more current is required,

then a separate power connector and a regulator must be designed on a

daughter card. Additional circuitry can add extra loading to signals,

decreasing their maximum effective speed.

Analog Devices does not support and is not responsible for the

effects of additional circuitry.
