TLC193, TLC393

DUAL MICROPOWER LinCMOS

™ VOLTAGE COMPARATOR

SLCS115D – DECEMBER 1986 – REVISED JANUARY 1999

10

POST OFFICE BOX 655303

TYPICAL CHARACTERISTICS

Table of Graphs

FIGURE

VIO

Input offset voltage

Distribution

4

IIB

Input bias current

vs Free-air temperature

5

CMRR

Common-mode rejection ratio

vs Free-air temperature

6

kSVR

Supply-voltage rejection ratio

vs Free-air temperature

7

VOL

Low level output voltage

vs Low-level output current

8

VOL

Low-level output voltage

vs Free-air temperature

9

IOH

Low level output current

vs High-level output voltage

10

IOH

Low-level output current

gg

vs Free-air temperature

11

IDD

Supply current

vs Supply voltage

12

IDD

Supply current

yg

vs Free-air temperature

13

tPLH

Low-to-high level output propagation delay time

vs Supply voltage

14

tPHL

High-to-low level output propagation delay time

vs Supply voltage

15

Low-to-high-level output response

Low-to-high level output propagation delay time

16

High-to-low level output response

High-to-low level output propagation delay time

17

tf

Fall time

vs Supply voltage

18

Figure 4

VDD = 5 V

VIC = 2.5 V

TA = 25°C

–5

–4

–3

–2

–1

0

1

2

3

4

5

VIO – Input Offset Voltage – mV

DISTRIBUTION OF INPUT

100

90

80

70

60

50

40

30

20

10

0

Figure 5

TA – Free-Air Temperature – °C

25

50

75

100

125

10

1

0.1

0.01

0.001

INPUT BIAS CURRENT

vs

VDD = 5 V

VIC = 2.5 V

† Data at high and low temperatures are applicable only within the rated operating free-air temperature ranges of the various devices.
