background image
Rev. 00
Rev. 00
December 2007
December 2007
www.ZLED.com
www.ZLED.com
서식번호 : SSC-QP-7-07-24 (Rev.00)
<080226> Rev. 0.2
4. Reliability Tests
Item
Condition
Note
Failures
Life Test
T
a = RT, IF = 30mA
1000hrs
0/22
0/22
0/22
Thermal Shock
T
a = -50ºC (30min) ~ 105º (30min)
(Transfer time : 10sec, 1Cycle = 1hr)
100
cycles
0/40
ESD
(Human Body Model)
1kV, 1.5kΩ ; 100pF
1 time
0/22
0/22
High Temperature Storage
T
a = 105ºC
1000hrs
0/22
Low Temperature Storage
T
a = -50ºC
1000hrs
0/22
Temperature Humidity
Storage
T
a = 85ºC, RH = 85%
1000hrs
0/22
Temperature Humidity
Operating
T
a = 85ºC, RH = 85%,
I
F = 15mA
100hrs
0/22
High Temperature Operating
T
a =100ºC, IF = 10mA
1000hrs
Resistance to soldering Heat
T
s = 255 ± 5ºC, t = 10sec
1 time
Low Temperature Operating
T
a = -40ºC, IF = 20mA
1000hrs
< Judging Criteria For Reliability Tests >
USL[1] X 1.2
V
F
USL X 2.0
I
R
Ф
V
LSL [2] X 0.7
Notes :
[1] USL : Upper Standard Level
[2] LSL : Lower Standard Level.
