Section 2 CPU

Rev.1.00 Jun. 07, 2006 Page 44 of 1102

REJ09B0294-0100

2.7.2

Table of Instructions Classified by Function

Tables 2.4 to 2.11 summarize the instructions in each functional category. The notation used in

these tables is defined in table 2.3.

Table 2.3

Operation Notation

Description

General register (destination)*

General register (source)*

General register*

ERn

General register (32-bit register)

(EAd)

Destination operand

(EAs)

Source operand

EXR

Extended control register

CCR

Condition-code register

VBR

Vector base register

SBR

Short address base register

N (negative) flag in CCR

Z (zero) flag in CCR

V (overflow) flag in CCR

C (carry) flag in CCR

Program counter

Stack pointer

#IMM

Immediate data

disp

Displacement

Addition

−

Subtraction

Multiplication

Division

∧

Logical AND

∨

Logical OR

⊕

Logical exclusive OR

→

Move

∼

Logical not (logical complement)

:8/:16/:24/:32

8-, 16-, 24-, or 32-bit length

Note:

General registers include 8-bit registers (R0H to R7H, R0L to R7L), 16-bit registers (R0

to R7, E0 to E7), and 32-bit registers (ER0 to ER7).
