Rev.1.00 Jun. 07, 2006 Page v of lii

Configuration of This Manual

This manual comprises the following items:

1. General Precautions on Handling of Product

2. Configuration of This Manual

3. Preface

4. Contents

5. Overview

6. Description of Functional Modules

• CPU and System-Control Modules

• On-Chip Peripheral Modules

The configuration of the functional description of each module differs according to the

module. However, the generic style includes the following items:

i) Feature

ii) Input/Output Pin

iii) Register Description

iv) Operation

v) Usage Note

When designing an application system that includes this LSI, take notes into account. Each section

includes notes in relation to the descriptions given, and usage notes are given, as required, as the

final part of each section.

7. List of Registers

8. Electrical Characteristics

9. Appendix

10. Main Revisions and Additions in this Edition (only for revised versions)

The list of revisions is a summary of points that have been revised or added to earlier versions.

This does not include all of the revised contents. For details, see the actual locations in this

manual.

11. Index
