48 / 78 page

w w w. g e e h y. c o m

P a g e 47

Symbol

Parameter

Condition

Minimum

value

Maximum

value

Unit

tdis(SO)(2)(4)

Disable time of data output

Slave Mode

tv(SO)(2)(1)

Effective time of data output

Slave mode (after enabling the

edge)

19.3

tv(MO)(2)(1)

Effective time of data output

Master mode (after enabling the

edge)

7.6

th(SO)(2)

Data output hold time

Slave mode (after enabling the

edge)

10.7

th(MO)(2)

Master mode (after enabling the

edge)

The SPI1 feature of remapping needs to be further determined.

The data are calculated and are not tested in production.

The minimum value represents the minimum time to drive the output, and the maximum value

represents the maximum time to make the data valid.

The minimum value represents the minimum time to disable the output, and the maximum value

represents the maximum time to put the data cable in high-impedance state.
