 11 / 78 page
background image
w w w. g e e h y. c o m
P a g e 10
Name
Abbreviations
Definitions
function
multiplexing
function
Redefining
function
Select this function through AFIO remapping register
Table3 APM32F103xB Pin Function Description
Pin Name
Pin No.
Type
(1)
Main function (3)
Optional multiplexing function
(After reset)
Default
multiplexing
function
Redefining
function
PE2
-
-
1
-
I/O
FT
PE2
TRACECK
-
PE3
-
-
2
-
I/O
FT
PE3
TRACED0
-
PE4
-
-
3
-
I/O
FT
PE4
TRACED1
-
PE5
-
-
4
-
I/O
FT
PE5
TRACED2
-
PE6
-
-
5
-
I/O
FT
PE6
TRACED3
-
VBAT
1
1
6
-
S
-
VBAT
-
-
PC13-
TAMPER-RTC(4)
2
2
7
-
I/O
-
PC13(3)
TAMPER-RTC
-
PC14-
OSC32_IN(4)
3
3
8
-
I/O
-
PC14(3)
OSC32_IN
-
PC15-
OSC32_OUT(4)
4
4
9
-
I/O
-
PC15(3)
OSC32_OUT
-
VSS_5
-
-
10
-
S
-
VSS_5
-
-
VDD_5
-
-
11
-
S
-
VDD_5
-
-
OSC_IN
5
5
12
2
I
-
OSC_IN
-
PD0(5)
OSC_OUT
6
6
13
3
O
-
OSC_OUT
-
PD1(5)
NRST
7
7
14
4
I/O
-
NRST
-
-
PC0
-
8
15
-
I/O
-
PC0
ADC12_IN10
-
PC1
-
9
16
-
I/O
-
PC1
ADC12_IN11
-
PC2
-
10
17
-
I/O
-
PC2
ADC12_IN12
-
PC3
-
11
18
-
I/O
-
PC3
ADC12_IN13
-
VSSA
8
12
19
5
S
-
VSSA
-
-
VREF-
-
-
20
-
S
-
VREF-
-
-
VREF+
-
-
21
-
S
-
VREF+
-
-
VDDA
9
13
22
6
S
-
VDDA
-
-
PA0-WKUP
10
14
23
7
I/O
-
PA0
WKUP/
USART2_CTS(6)/
ADC12_IN0/
TMR2_CH1_ETR(6)
-
PA1
11
15
24
8
I/O
-
PA1
USART2_RTS(6)/
ADC12_IN1/
TMR2_CH2(6)
-
