SSM2537
Data Sheet
Rev. 0 | Page 4 of 16
Parameter
Symbol
Test Conditions/Comments
Min
Typ
Max
Unit
Supply Current, Modulator
I
VDD
Dither input, 8 Ω + 33 µH load
VDD = 1.8 V, f
S = 64×
0.3
mA
VDD = 1.8 V, f
S = 128×
0.6
mA
Standby Current
VDD = 1.8 V, f
S = 64×
37
µA
VDD = 1.8 V, f
S = 128×
68
µA
Shutdown Current
VDD = 1.8 V
1.6
µA
NOISE PERFORMANCE
Output Voltage Noise
e
n
Dither input, A-weighted
PVDD = 3.6 V, f
S = 64×
25
µV
PVDD = 3.6 V, f
S = 128×
27
µV
PVDD = 5.0 V, f
S = 64×
33
µV
PVDD = 5.0 V, f
S = 128×
30
µV
Signal-to-Noise Ratio
SNR
P
O = 1.4 W, PVDD = 5.0 V, RL = 8 Ω,
A-weighted
f
S = 64×
102
dB
f
S = 128×
102
dB
DIGITAL INPUT/OUTPUT SPECIFICATIONS
Table 2.
Parameter
Symbol
Min
Typ
Max
Unit
INPUT SPECIFICATIONS
Input Voltage High
V
IH
PCLK, PDAT, LRSEL Pins
0.7 × VDD
3.6
V
Input Voltage Low
V
IL
V
PCLK, PDAT, LRSEL Pins
−0.3
0.3 × VDD
V
Input Leakage Current High
I
IH
PDAT, LRSEL Pins
1
µA
PCLK Pin
3
µA
Input Leakage Current Low
I
IL
PDAT, LRSEL Pins
1
µA
PCLK Pin
3
µA
Input Capacitance
5
pF
