8 / 20 page

NYP

General Specifications

Performance Specifications

Item

NYP65-@1@@@

NYP13-@1@@@

NYP65-@0@@@

NYP13-@0@@@

NYP3A-@0@@@

Main

system

CPU

CPU type

Intel® Core™

i5-1145GRE

Intel® Core™

i3-1115GRE

Intel® Core™

i5-1145GRE

Intel® Core™

i3-1115GRE

Intel Atom®

x6425RE

Cores / Threads

4 / 8

2 / 4

4 / 8

2 / 4

4 / 4

CPU base frequency

1.5 GHz

2.2 GHz

1.5 GHz

2.2 GHz

1.9 GHz

Maximum turbo

frequency

4.1 GHz

3.9 GHz

4.1 GHz

3.9 GHz

−

Cache

8 MB

6 MB

8 MB

6 MB

1.5 MB

Cooling details

Passive cooling (fanless)

Intel CPU category

Industrial (100% operation minimal 10yr)

Memory

Memory size

8, 16, 32, 64 GB

4, 8, 16, 32 GB

Memory type

DDR4

Package Memory

Format

SO-DIMM

Serial

Presence

Detect

(SPD)

Speed

grade

3200 MT/s

CAS

latency

CL17

Trusted platform module (TPM)

Available

Graphics controller

Intel® Iris® Xe

Graphics. Up to four

independent

screens.

Intel® UHD

Graphics. Up to four

independent

screens.

Intel® Iris® Xe

Graphics. Up to four

independent

screens.

Intel® UHD

Graphics. Up to four

independent

screens.

Intel® UHD

Graphics. Up to four

independent

screens.

Intel® Iris® Xe

Graphics (80 EU)

Intel® UHD

Graphics (48 EU)

Intel® Iris® Xe

Graphics (80 EU)

Intel® UHD

Graphics (48 EU)

Intel® UHD

Graphics (32 EU)

Watchdog

Yes

Operating

system

Windows OS

Windows 10 IoT Enterprise 2021 LTSC - 64 bit

Storage

devices

Drives

Hard Disk Drive

−

Solid

State

Drive

SLC type

−

MLC type

−

3DTLC type 128 GB, 256 GB, 512 GB, 1 TB

128 GB, 256 GB, 512 GB

Drive bays (HDD/SSD)

CFast slot

Hardware-RAID support

N/A

Connectors

Power connector

24 VDC

I/O connector

2 inputs and 1 output

USB2.0

Type-A

Number of ports

−

Maximum current

−

Maximum cable length

−

USB3.0

Type-A

Number of ports

Maximum current

900 mA

Maximum cable length 3 m

Ethernet

connectors

Number of ports

Physical layer

10BASE-T, 100BASE-TX, 1000BASE-T or 2500BASE-T

Maximum

transmission distance

between Ethernet

switch and node

100 m

DVI-I

connector

Video interface

−

Resolution

−

Maximum cable length

−

DisplayPort

Resolution

Up to 4,096 x 2,304 at 60 Hz

Maximum cable length 3 m
