SOR-R3

www.eravant.com | 424-757-0168 | support@eravant.com

Copyright © 2023 by Eravant

2/2

Final Rev 1.2

Mechanical Outline:

Unless otherwise specified, all dimensions are in inches [millimeters])

NOTE:

•

The regulator is designed for the designated Gunn oscillator only room temperature.

•

Eravant reserves the right to change the information presented without notice.

CAUTION:

•

Do not use the regulator as a universal product to bias non-designated oscillators. To do so will cause equipment damage.

•

For 1.35 mm, 1.85 mm, 2.4 mm, 2.92 mm, and SMA connectors proper torque should be applied: 8.0 ± 0.15 inch-pounds

(0.90 ± 0.02 Nm). Torque wrench model SCH-08008-S1 is highly recommended
