isc Silicon NPN Darlington Power Transistor

ISCND454M

ELECTRICAL CHARACTERISTICS

TC=25℃ unless otherwise specified

SYMBOL

PARAMETER

CONDITIONS

MIN

TYP.

MAX

UNIT

VCEO

Collector-Emitter Voltage

IC= 3mA; IB= 0

500

-

-

V

VCBO

Collector-Base Voltage

IC= 3mA; IE= 0

500

-

-

V

VEBO

Emitter-Base Voltage

IE= 0.1mA; IC= 0

5

-

-

V

VCE(sat)

Collector-Emitter Saturation Voltage

IC= 12.5A; IB= 0.125A

-

-

1.8

V

ICBO

Collector Cutoff Current

VCB=500V;IE=0

-

-

3.0

mA

ICEO

Collector Cutoff Current

VCE= 500V; IB= 0

-

-

3.0

mA

IEBO

Emitter Cutoff Current

VEB= 5V; IC= 0

-

-

2.0

mA

hFE

DC Current Gain

IC= 5A, VCE=10V

1800

-

2500
