Creating duplicate objects

Based on one object, you can create multiple copies with the same appearance and settings by specifying an

off set value for an array variable. This makes screen creation faster and easier.

Set the number of horizontal and vertical objects, and their spacing.

When an array variable is specified, you can duplicate the object by adding the specified

offset value to the element number.

Right-click

The combination of VNC and FTP

allows you to capture the NA

screens from the connected PC.

NA screen capture

The screens displayed on the NA Series can be captured and saved in the SD card inserted

in the NA Series or the USB memory connected to the NA Series.

• When a screen of the NA Series is required to create a machine operation manual

• When the current screen is required to save as proof of a trouble

Supported format: PNG

Data input order

The data input order can be set.

When numeric values are entered conse-

cutively, the focus automatically moves to

the next Data Edit object by touching the

Enter key. Input errors and input time can

be minimized.

Enable

AutoNavigateKeypads

in the properties of

the page to enter

data consecutively.

The data input

order can be set in

the property of the

Data Edit object.

The focus automatically

moves to the next object

by touching the Enter key.
