Block Diagram

RSB-4680

Ordering Information

Part Number

CPU

Memory

Flash

HDMI

VGA

LVDS

LAN

Serial Port

SATA

USB

System

Bus

SD

CAN

Bus

Operating

Temperature

RSB-4680CQ-XNA1E

Rockchip RK3288

Quad core, 1.6GHz

2 GB

8 GB

1

1

1

1

1 x 4-wire RS-232/485

1 x 2-wire RS-232/Debug port

4 x 4-wire RS-232

_

5 x USB Host

1 x USB OTG

_

1

_

0 ~ 60 °C

RSB-4680WQ-XNA1E

Rockchip RK3288K

Quad core, 1.6GHz

2 GB

8 GB

1

1

1

1

1 x 4-wire RS-232/485

1 x 2-wire RS-232/Debug port

4 x 4-wire RS-232

_

5 x USB Host

1 x USB OTG

_

1

_

-20 ~ 85 °C

Packing List

Part Number

Description

RSB-4680

RSB-4680 3.5'' SBC

Optional Accessories

Part Number

Description

96PSA-A36W12W7-5

ADP A/D 100-240V 36W 12V C6 LOCK DC JACK

170203183C

Power Cord 3P EU 10A 250V 183cm

170203180A

Power Cord 3P UK 10A 250V 183cm

1700001524

Power Cord UL 3P 10A 125V 180cm

1700008921

Power Cord PSE 3P 12A 125V 183cm

1700019146

Power Cord CCC 3P 10A 250V 183cm

1700021565-01

Debug cable

EWM-W172H01E

802.11ac/a/b/g/n 2T2R WIFI BT 4.2 RTL8822BU-CG Half Mini PCIe

Module

9656EWMG00E

Half-size miniPCIe to miniPCIe bracket set

1750005885

Antenna L=23cm MALFR8-3230A-00X00R

1750008717-01

Dipole Ant. D.B 2.4/5G WIFI 3dBi SMA/M-R BLK

EWM-C117FL06E*

LTE 4G,3G WCDMA/DC-HSPA+, 2G module, MPCI-L280H

968AD00081*

Qucetel EC20CEFA Mini-PCIe 4G module for China

1750006264

Antenna cable SMA(F)/MHF 15cm

1750008303-01

Antenna AN0727-64SP6BSM

SQF-MSDM1-8G-21C

SQF MICRO SD C10 MLC 8G (-25 ~ 85 °C)

IDK-1107WR-40WVA1E

7" LED PANEL 2.5A/3A 250V 1.83cm400N with 4WR touch, 800 x 480 (G)

1700028571-01

LVDS cable for IDK-1107WR

1700028572-01

LCD blacklight cable for IDK-1107WR

* Please contat us to get suitiable celluar module for your region.

External I/O

DC-in

RS-232/485

HDMI

Reset button

OTG

VGA

Ethernet

USB

Dimensions

Unit: mm

102

92.7

2-Ø6

Ø6.4

4-Ø3.2

86.55

80.1

59.26

27.2

98.7

80.86

39.14

20.5

ROCKCHIP

RK3288

2 GB DDR3

eMMC

DDR

8 GB eMMC

ALC5660

CH7517

VGA

HDMI

LVDS

GbE RJ45

TI DP83867

1 x RS232 w/2wire

1 x RS232/485

w/4wire

Line out, Mic in

pin header

Speaker out

pin header

2 x RS232 w/4wire

2 x RS232 w/4 wire

2 x USB type A

Mini-PCIe slot

SIM slot

CP2105

1 x I2C

8 x GPIO

Micro SD slot

MAX3243

2 x MAX3243

1x MAX3243

1 x SN75176

1 x USB OTG

Debug port

Jumper

SPI

UART1/3

UART4

USB OTG

UART2

UART0

SDIO0

USB1

USB2

USB Hub

(1 to 4)

USB Hub

(1 to 4)

M.2 E key

3 x USB pin header

RGMII

I2S

I2C

SDIO2

GPIO

eDP

HDMI

LVDS

1 x SPI

SPI

4 MB NOR Flash

2 x MAX3243
