Data Sheet

ADL8106

ELECTRICAL SPECIFICATIONS

analog.com

Rev. 0 | 5 of 26

50 GHz TO 54 GHz FREQUENCY RANGE

TCASE = 25°C, VDD1 = VDD2 = 3 V, and IDQ = 120 mA, unless otherwise stated. Adjust VGG1 between −2 V to 0 V to achieve an IDQ = 120 mA

typical.

Table 5.

Parameter

Min

Typ

Max

Unit

Test Conditions/Comments

FREQUENCY RANGE

50

54

GHz

GAIN

20.5

dB

Gain Variation over Temperature

0.031

dB/°C

RETURN LOSS

Input

15

dB

Output

14.5

dB

OUTPUT

OP1dB

19

dBm

PSAT

20

dBm

OIP3

23

dBm

POUT per tone = 0 dBm with 1 MHz tone spacing

NOISE FIGURE

4

dB

SUPPLY

IDQ

120

mA

Adjust VGG1 to achieve IDQ = 120 mA typical

VDD

2

3

3.5

V
