 54 / 60 page
background image
EM62100
65 COM/132 SEG STN LCD Driver
48 •
•••
Product Specification (V1.1) 09.13.2005
(This specification is subject to change without further notice)
Rating
Item
Symbol Condition & Application Pin
Min.
Typ.
Max.
Unit
VOUT1
Booster output voltage on
VOUT pin (x5)
5xVEE
x0.95
5xVEE
x0.98
5xVEE
VOUT2
Booster output voltage on
VOUT pin (x4)
4xVEE
x0.95
4xVEE
x0.98
4xVEE
VOUT3
Booster output voltage on
VOUT pin (x3)
3xVEE
x0.95
3xVEE
x0.98
3xVEE
Supply
Step-up
Output
Voltage
VOUT4
Booster output voltage on
VOUT pin (x2)
2xVEE
x0.95
2xVEE
x0.98
2xVEE
V
Base Voltage
VREG
Ta=25°C
2.04
2.10
2.16
V
NOTE
1. Ensure that the voltage levels of V1, V2, V3, and V4 are in such a way that
V0 V1 V2 V3 V4 VSS.
2. Unless otherwise specified, VSS = 0V, VDD = 1.8 - 3.6V ±10%, Ta = –40 to 85°C
