ED923R14 — Updated April 2019 — For latest specs visit www.legrand.us/wiremold

880MP Series Nonmetallic

Floor Boxes

communication services directly to the workstation or to any open

space location. The Modulink Floor Box is a gangable box that allow

a one-gang floor box to easily be turned into a two-or three-gang

box simply by ganging together individual boxes. This floor box

has many applications including commercial offices, retail stores,

malls, financial and government institutions.

Compliance

cULus Listed Nonmetallic Outlet Boxes. File E110748 Guide QCMZ.

Listed by Underwriters Laboratories Inc. to their standard UL514A, 514C, 514D,

and Canadian standard C22.2.

Features & Benefits

• Multiple service capability. Eliminates the cost of a

separate floor box and cover to accommodate

communication service.

• Depth markings on exterior of the box. Makes floor box

depth calculations quick and easy. Reduces installation time

and labor costs.

• 2" (51mm) conduit openings. Provides the largest conduit

feed in the industry. Meets customer requirements for

greater communication cable capacity.

• Ratchet adjusting ring. Allows connection of cover flange

without glue or mechanical fasteners. Reduces installation

time and cost by providing 10° of post-pour adjustment of

the cover flange.

• Conduit reducers and plugs provided. Allows direct

reduction from 2" to 1 1/2" or 1 1/4" (51mm to 38mm or

32mm) conduit. Reduces installation time by providing direct

reduction and separate plugs by eliminating the need to

cut out plugs to form reducers.

• Brushed aluminum covers for power applications. 830CK

Series Aluminum Covers have been redesigned to now

accept threaded conduit when passing through power

cables.

• Brass and brushed aluminum covers to accept single

locking power receptacles. New 828DLR Series provides

single flip lid cover.

• Cubic inch markings on the interior of the box. No need to

calculate capacity for wire fill, saving installation time.

• Ratchet adjusting ring has built-in fiber storage. Provides

bend radius control for fiber optic cables.

• Pass-through capability. Can feed multiple gangs from a

single cable feed location. Reduces total installation time.

• Modular design and gangability. One SKU to order boxes

with the ability to configure boxes as needed on the job site.

• Internal spacer. Protects box from deformation of the

sidewalls when high temperature additives are used in the

concrete pour.

• Redesigned mudcap. High impact mudcap protects the box

from damage when heavy equipment such as scissor lift

trucks come in contact with the box during installation.

• TopGuard protection. Activation covers for the 880MP PVC

box are TopGuard protected. These cover assemblies keep

out water, dirt, and debris from the power and

communication compartments.

• Communication connectivity options. Accepts industry

standard and proprietary devices from a wide range of

manufacturers to provide a seamless and aesthetically

pleasing interface for voice, data, audio, and video

applications at the point-of-use. A wide selection of data and

and Series II devices.

• Commercial

• Education

• Entertainment

• Healthcare

• Retail

• Government

Vertical Markets

Protection from water,

dirt, and debris.

Download this product’s PEP ecopasport

®

environmental product declaration at

www.legrand.us/resources-and-downloads.

This declaration conforms with ISO 14025 and

14040 and is in alignment with EN 15804.

Single-gang Modulink 880 Series Nonmetallic Floor Box

can be ganged together to become two- or three-gang

boxes to provide multiple services.
