ED923R14 — Updated April 2019 — For latest specs visit www.legrand.us/wiremold

5

Modulink 880MP Series Brushed Aluminum Cover Plate Flanges Ordering Information

Country of Origin: China

828R-TCAL

Brushed Aluminum Duplex Cover

Plate – Flip lids. Can also be used

with a 106 type communication

adapter.

Country of Origin: China

830CKTCAL-1

Brushed Aluminum Cover Plate –

Power or communication plate with

2" (51mm) and 1" (25mm) plugs.

3.290"

(83.6mm)

4.310"

(109.5mm)

3.290"

(83.6mm)

4.310"

(109.5mm)

3.290"

(83.6mm)

4.310"

(109.5mm)

NOTE: Acceptable for use with

threaded conduit when passing

through power cables.

3.290"

(83.6mm)

4.310"

(109.5mm)

3.290"

(83.6mm)

4.310"

(109.5mm)

3.290"

(83.6mm)

4.310"

(109.5mm)

3.290"

(83.6mm)

4.310"

(109.5mm)

Country of Origin: China

828GFITCAL

Brushed Aluminum GFI

Cover Plate – May be used

Connectivity Systems in

conjunction with 817B, 827B,

and 837B Flanges.

Country of Origin: China

828DPGFITCAL

Brushed Aluminum Rectangular

Cover Plate – Allows for mounting

of a duplex style receptacle with a

rectangular style flip lid cover.

Country of Origin: China

828DLRAL

Brushed Aluminum Single Locking

Receptacle Cover Plate –

Single flip lid cover for 20A or 30A

single locking receptacles. Device

opening is 2 5/8" (67mm). For use

with maximum female locking device

of 1.58" diameter, and maximum

male plug face of 2.25" diameter.

Country of Origin: China

830CKTCAL

Brushed Aluminum Cover Plate –

Power or communication plate with

2" (51mm) and 1 1/4" (32mm) plugs.

NOTE: Brass covers and flanges are not interchangeable with aluminum or nonmetallic covers and flanges.

Nonmetallic covers are interchangeable with aluminum flanges.

Country of Origin: China

830CKTCAL-3/4

Brushed Aluminum Cover Plate –

Power or communication plate

with 2" (51mm) and 3/4" (19.1mm)

plugs.

Country of Origin: China

830CKTCAL-1/2

Brushed Aluminum Cover Plate –

Power or communication plate

with 2" (51mm) and 1/2" (12.7mm)

plugs.

Country of Origin: China

828MAAP

A/V Adapter Plate – Sheet metal

adapter plate that accepts two (2)

Extron

device plates (sold separately). For

use with 828GFITC, 828GFITCAL

or 828PRGFI cover plates.

(Sold separately.)

NOTE: Acceptable for use with

threaded conduit when passing

through power cables.

NOTE: Acceptable for use with

threaded conduit when passing

through power cables.

NOTE: Acceptable for use with

threaded conduit when passing

through power cables.

All cover assemblies

for the Modulink 880MP

Series Floor Box have

TopGuard protection.
