ED923R14 — Updated April 2019 — For latest specs visit www.legrand.us/wiremold

6

Modulink 880MP Series Powder-Coated Aluminum Cover Plate Flanges Ordering Information

Country of Origin: China

817TCAL-BK

817TCAL-GY

817TCAL-BS

817TCAL-NK

817TCAL-BZ

One-Gang Powder-Coated

Aluminum Combination Carpet

and Tile Flange – Accepts

MAB3S2 Series II adapters and

Wiremold CM Series inserts, sold

separately. Flanges are available in

five decorative colors: black, gray,

brass, nickel and bronze.

Country of Origin: China

828GFITCAL-BK

828GFITCAL-GY

828GFITCAL-BS

828GFITCAL-NK

828GFITCAL-BZ

Powder-Coated Aluminum

Rectangular Cover Plate – Allows

for mounting a duplex receptacle

(Decorator or GFCI style) with a

rectangular flip cover.

NOTE: Acceptable for use with

threaded conduit when passing

through power cables.

Country of Origin: China

827TCAL-BK

827TCAL-GY

827TCAL-BS

827TCAL-NK

827TCAL-BZ

Two-Gang Powder-Coated

Aluminum Combination Carpet

and Tile Flange – Accepts

MAB3S2 Series II adapters and

Wiremold CM Series inserts, sold

separately. Flanges are available in

five decorative colors: black, gray,

brass, nickel and bronze.

Country of Origin: China

837TCAL-BK

837TCAL-GY

837TCAL-BS

837TCAL-NK

837TCAL-BZ

Three-Gang Powder-Coated

Aluminum Combination Carpet

and Tile Flange – Accepts

MAB3S2 Series II adapters and

Wiremold CM Series inserts, sold

separately. Flanges are available in

five decorative colors: black, gray,

brass, nickel and bronze.

Country of Origin: China

828R-TCAL-BK

828R-TCAL-GY

828R-TCAL-BS

828R-TCAL-NK

828R-TCAL-BZ

Powder-Coated Aluminum

Duplex Cover Plate – Flip lids.

Can also be used with a

106 type communication adapter.

6.080"

(154.4mm)

5.060"

(128.5mm)

6.080"

(154.4mm)

9"

(229mm)

6.080"

(154.4mm)

13.81"

(335mm)

3.290"

(83.6mm)

4.310"

(109.5mm)

Country of Origin: China

829CKAL-1BK

829CKAL-1GY

829CKAL-1BS

829CKAL-1NK

829CKAL-1BZ

Powder-Coated Aluminum Cover

Plate – Power or communication

plate with 2" (51mm) and 1"

(25mm) plugs.Covers are available

in five decorative colors: black,

gray, brass, nickel and bronze.

Country of Origin: China

829CKAL-3/4BK

829CKAL-3/4GY

829CKAL-3/4BS

829CKAL-3/4NK

829CKAL-3/4BZ

Powder-Coated Aluminum Cover

Plate – Power or communication

plate with 2" (51mm) and 3/4"

(19.1mm) plugs. Covers are

available in five decorative colors:

black, gray, brass, nickel and

bronze.

Country of Origin: China

828MAAP

A/V Adapter Plate – Sheet metal

adapter plate that accepts two (2)

Extron

device plates (sold separately). For

use with 828GFITC, 828GFITCAL

or 828PRGFI cover plates.

(Sold separately.)

3.290"

(83.6mm)

4.310"

(109.5mm)

3.290"

(83.6mm)

4.310"

(109.5mm)

3.290"

(83.6mm)

4.310"

(109.5mm)

NOTE: Brass covers and flanges are not interchangeable with aluminum or nonmetallic

covers and flanges. Nonmetallic covers are interchangeable with aluminum flanges.

All cover assemblies

for the Modulink 880MP

Series Floor Box have

TopGuard protection.
