ED923R14 — Updated April 2019 — For latest specs visit www.legrand.us/wiremold

3

Modulink 880MP Series Solid Brass Cover Plate Flanges Ordering Information

Country of Origin: China

817B

One-Gang Brass Combination

Carpet & Tile Flange – Accepts

MAB3S2 Series II adapters and

Wiremold CM Series inserts,

sold separately.

Country of Origin: China

837B

Three-Gang Brass Combination

Carpet and Tile Flange – Accepts

MAB3S2 Series II adapters and

Wiremold CM Series inserts,

sold separately.

6.080"

(154.4mm)

5.060"

(128.5mm)

Country of Origin: China

827B

Two-Gang Brass Combination

Carpet and Tile Flange – Accepts

MAB3S2 Series II adapters and

Wiremold CM Series inserts,

sold separately.

6.080"

(154.4mm)

9"

(229mm)

6.080"

(154.4mm)

13.81"

(335mm)

Modulink 880MP Series Metal Cover Plates Ordering Information

Country of Origin: China

828R

Brass Duplex Cover Plate – Flip

lids. Can also be used with a 106

type communication adapter.

3.156"

(80.2mm)

4.182"

(106.2mm)

Country of Origin: China

828GFITC

Brass GFI Cover Plate – May be

Connectivity Systems in

conjunction with 817B, 827B,

and 837B Flanges.

Country of Origin: China

828DPGFITC

Brass Rectangular Cover Plate –

Allows for mounting of a duplex

style receptacle with a

rectangular style flip lid cover.

3.156"

(80.2mm)

4.182"

(106.2mm)

3.156"

(80.2mm)

4.182"

(106.2mm)

NOTE: Brass covers and flanges are not interchangeable with aluminum or nonmetallic covers

and flanges. Nonmetallic covers are interchangeable with aluminum flanges.

Country of Origin: China

828DLR

Brass Single Locking Receptacle

Cover Plate – Single flip lid cover

for 20A or 30A single locking

receptacles. Device opening is

2 5/8" (67mm). For use with

maximum female locking device

of 1.58" diameter, and maximum

male plug face of 2.25" diameter.

Country of Origin: China

828SPTC

Brass Duplex Cover Plate –

Screw plugs. Screw plugs are

1 1/2" (38mm) in diameter.

3 1/8"

(79mm)

4 1/8"

(105mm)

Country of Origin: China

828STC

Brass Communication Cover

Plate – Data slides. Feed through

only, not for use with a mounting

plate for communication jacks.

3 1/8"

(79mm)

4 1/8"

(105mm)

All cover assemblies

for the Modulink 880MP

Series Floor Box have

TopGuard protection.
