SPECIFICATIONS

Part Number

Inductance

(nH)

Available

Tolerance

Q

Min.

Test

Freq.

(MHz)

Q Typ.

@

100MHz

Q Typ.

@

800MHz

Q Typ.

@

1000MHz

SRF

Min.

(GHz)

DCR

Max.

(W)

IDC

Max.

(mA)

CTLL1005SF-1N0S

1.0

±0.3nH

8

100

11

34

36

10.00

0.10

400

CTLL1005SF-1N1S

1.1

±0.3nH

8

100

11

34

36

10.00

0.10

400

CTLL1005SF-1N2S

1.2

±0.3nH

8

100

11

34

36

10.00

0.10

400

CTLL1005SF-1N3S

1.3

±0.3nH

8

100

11

34

36

10.00

0.10

400

CTLL1005SF-1N5S

1.5

±0.3nH

8

100

11

34

36

6.00

0.10

300

CTLL1005SF-1N6S

1.6

±0.3nH

8

100

11

32

35

6.00

0.10

300

CTLL1005SF-1N8S

1.8

±0.3nH

8

100

11

30

34

6.00

0.10

300

CTLL1005SF-2N0S

2.0

±0.3nH

8

100

10

29

33

6.00

0.20

300

CTLL1005SF-2N2S

2.2

±0.3nH

8

100

10

29

33

6.00

0.20

300

CTLL1005SF-2N4S

2.4

±0.3nH

8

100

10

29

32

6.00

0.20

300

CTLL1005SF-2N7S

2.7

±0.3nH

8

100

10

29

32

6.00

0.20

300

CTLL1005SF-3N0S

3.0

±0.3nH

8

100

10

29

32

6.00

0.20

300

CTLL1005SF-3N3S

3.3

±0.3nH

8

100

10

29

32

6.00

0.20

300

CTLL1005SF-3N6S

3.6

±0.3nH

8

100

10

28

31

4.00

0.20

300

CTLL1005SF-3N9S

3.9

±0.3nH

8

100

10

28

31

4.00

0.20

300

CTLL1005SF-4N3S

4.3

±0.3nH

8

100

10

28

31

4.00

0.20

300

CTLL1005SF-4N7S

4.7

±0.3nH

8

100

10

28

31

4.00

0.20

300

CTLL1005SF-5N1S

5.1

±0.3nH

8

100

10

28

30

4.00

0.30

300

CTLL1005SF-5N6S

5.6

±0.3nH

8

100

10

28

30

4.00

0.30

300

CTLL1005SF-6N2S

6.2

±0.3nH

8

100

10

27

30

3.90

0.30

300

CTLL1005SF-6N8_

6.8

±5%, ±10%

8

100

10

27

30

3.90

0.30

300

CTLL1005SF-7N5_

7.5

±5%, ±10%

8

100

10

27

30

3.70

0.40

300

CTLL1005SF-8N2_

8.2

±5%, ±10%

8

100

10

27

30

3.60

0.40

300

CTLL1005SF-9N1_

9.1

±5%, ±10%

8

100

10

27

30

3.40

0.40

300

CTLL1005SF-10N_

10

±5%, ±10%

8

100

10

27

30

3.20

0.40

300

CTLL1005SF-12N_

12

±5%, ±10%

8

100

10

26

29

2.70

0.50

300

CTLL1005SF-15N_

15

±5%, ±10%

8

100

10

26

28

2.30

0.50

300

CTLL1005SF-18N_

18

±5%, ±10%

8

100

10

25

27

2.10

0.60

300

CTLL1005SF-20N_

20

±5%, ±10%

8

100

10

25

26

2.00

0.60

300

CTLL1005SF-22N_

22

±5%, ±10%

8

100

10

25

25

1.90

0.60

300

CTLL1005SF-27N_

27

±5%, ±10%

8

100

10

25

23

1.60

0.70

300

CTLL1005SF-33N_

33

±5%, ±10%

8

100

10

22

22

1.30

0.80

200

CTLL1005SF-39N_

39

±5%, ±10%

8

100

10

22

19

1.20

1.00

200

CTLL1005SF-43N_

43

±5%, ±10%

8

100

10

21

16

1.10

1.10

200

CTLL1005SF-47N_

47

±5%, ±10%

8

100

10

21

16

1.00

1.10

200

CTLL1005SF-56N_

56

±5%, ±10%

8

100

10

18

13

0.75

1.20

200

CTLL1005SF-68N_

68

±5%, ±10%

8

100

10

18

9

0.75

1.40

180

CTLL1005SF-82N_

82

±5%, ±10%

8

100

10

13

-

0.75

2.40

150

CTLL1005SF-R10_

100

±5%, ±10%

8

100

10

12

-

0.70

2.60

150

CTLL1005SF-R12_

120

±5%, ±10%

8

100

10

-

-

0.60

2.80

150

CTLL1005SF-R15_

150

±5%, ±10%

8

100

10

-

-

0.55

3.20

100

CTLL1005SF-R18_

180

±5%, ±10%

8

100

10

-

-

0.50

3.70

100

CTLL1005SF-R22_

220

±5%, ±10%

8

100

12

-

-

0.45

4.00

100

CTLL1005SF-R27_

270

±5%, ±10%

8

100

12

-

-

0.40

4.50

100

CTLL1005SF-R33_

330

±5%, ±10%

6

50

-

-

-

0.35

7.00

50

Please specify tolerance code when ordering.

CTLL1005SF-6N8_

S = ±0.3nH, J = ±5%, K = ±10%

Manufacturer of Passive Components

800-684-5322 Inside US

949-453-1811 Outside US

Copyright © 2015 by CT Magnetics, DBA Central Technologies. All rights reserved.

CT Magnetics reserves the right to make improvements or change specifications without notice

REV 11.24.15

Multi-layer Chip Inductors - Ceramic

www.ctparts.com
