Multi-layer Chip Inductors - Ceramic

www.ctparts.com

CTLL1005SF

Series

From 1.0nH to 330nH

Not Shown at Actual Size

CHARACTERISTICS

PHYSICAL DIMENSIONS

Description: SMD ceramic core, multi-layer chip inductor for

high frequency.

Applications: Cellular telephones, bluetooth, computer

communications, radar detectors, automotive electronics, WLAN,

UWB, digital TV tuners, keyless remotes and miscellaneous high-

frequency circuits.

Operating Temperature: -55°C to +125°C

Inductance Tolerance: ±0.3nH, ±5%, ±10%

Packaging: Tape & Reel.

Additional Information: Additional electrical & physical

information available upon request.

Samples available. See website for ordering information.

D

A

D

B

C

Terminal

Electrode

Direction

Mark

A

B

C

D

1.00±0.15

0.50±0.15

0.50±0.15

0.25±0.10

0.04± 0.006

0.02±0.006

0.02±0.006

0.010±0.004

Size

mm

inches
