PRODUCT

PHASE SHIFTER

SPECIFICATION

DC TO 2, 4 AND 8 GHZ, COAXIAL

MODELS 6808

Sage Laboratories, Inc.

11 Huron Drive

Natick, MA 01760-1338

Tel: 508-653-0844

Fax: 508.653.5671

www.sagelabs.com

ORDERING INFORMATION

DRIVE SHAFT AND CONNECTOR OPTIONS:

1.

Only the following standard control options are available. The base model is available without additional options.

2.

Add suffix as designated below to the ordering model number.

MODEL # PLUS

DESCRIPTION

-1

Shaft Lock

-2

Turns Counter With Built In Shaft Lock

-4

Screw Driver Slot

-5

Control Knob

-14

Shaft Lock With Screw Driver Slot

-15

Shaft Lock With Control Knob

(-1) SHAFT LOCK

(-2) TURNS COUNTER W/ SHAFT LOCK

(-5) CONTROL KNOB

D= 0.5” L=0.65

MICSELLANIOUS:

1.

Sage Laboratories Inc. “Standard Warranty and Order Terms and Conditions” apply to all orders.

2.

All specifications subject to change without notice.

3.

Check “Ordering and Availability Listing” for delivery and ordering information.

4.

Contact our local Manufacturers Representative for pricing.

Specification Revision - 081804
