SSM3515

Data Sheet

Rev. A| Page 20 of 41

ADDR PIN SETUP AND CONTROL

The ADDR pin sets the device I2C address. See Table11 for details.

CLOCKING

In 3-wire mode (BCLK, FSYNC, SDATA), a BCLK signal must

be provided to the SSM3515 for correct operation. The BCLK

signal must have a minimum frequencyof 2.048 MHz.The BCLK

signal is used for internal clocking of the device. The BCLK rate

is detected automatically, but the sampling frequency must be

known to the device. The supported BCLK rates at 32 kHz to 48

kHz are 50, 64, 100, 128, 192, 200, 256, 384, 400, and 512 times

the sample rate.

Table 11. Pin Setup List

ADDR Pin

SCL Pin

SDA Pin

Control Mode

7-Bit I2C Address

TDM Slot

Connected to Ground Using a 47 kΩ Resistor

SCL

SDA

I2C

0x14

Open (No Connection)

SCL

SDA

I2C

0x15

Connected to 1.8 V Using a 47 kΩ Resistor

SCL

SDA

I2C

0x16

Connected to 1.8 V

SCL

SDA

I2C

0x17
