SSM2517

Data Sheet

Rev. B | Page 8 of 16

TYPICAL PERFORMANCE CHARACTERISTICS

100

0.1

0.01

0.001

0.01

0.1

OUTPUT POWER (W)

RL = 8Ω + 33µH

GAIN = 5V

SAMPLE RATE = 64×

(3.072MHz)

PVDD = 2.5V

PVDD = 3.6V

PVDD = 5V

Figure 4. THD + N vs. Output Power into 8 Ω, Gain = 5 V, fS = 64×

100

0.1

0.01

0.001

0.01

0.1

OUTPUT POWER (W)

RL = 8Ω + 33µH

GAIN = 3.6V

SAMPLE RATE = 64×

(3.072MHz)

PVDD = 2.5V

PVDD = 3.6V

PVDD = 5V

Figure 5. THD + N vs. Output Power into 8 Ω, Gain = 3.6 V, fS = 64×

100

0.1

0.01

0.001

0.01

0.1

OUTPUT POWER (W)

RL = 4Ω + 15µH

GAIN = 5V

SAMPLE RATE = 64×

(3.072MHz)

PVDD = 2.5V

PVDD = 5V

PVDD = 3.6V

Figure 6. THD + N vs. Output Power into 4 Ω, Gain = 5 V, fS = 64×

100

0.1

0.01

0.001

0.01

0.1

OUTPUT POWER (W)

RL = 8Ω + 33µH

GAIN = 5V

SAMPLE RATE = 128×

(6.144MHz)

PVDD = 2.5V

PVDD = 3.6V

PVDD = 5V

Figure 7. THD + N vs. Output Power into 8 Ω, Gain = 5 V, fS = 128×

100

0.1

0.01

0.001

0.01

0.1

OUTPUT POWER (W)

RL = 8Ω + 33µH

GAIN = 3.6V

SAMPLE RATE = 128×

(6.144MHz)

PVDD = 2.5V

PVDD = 5V

PVDD = 3.6V

Figure 8. THD + N vs. Output Power into 8 Ω, Gain = 3.6 V, fS = 128×

100

0.1

0.01

0.001

0.01

0.1

OUTPUT POWER (W)

RL = 4Ω + 15µH

GAIN = 5V

SAMPLE RATE = 128×

(6.144MHz)

PVDD = 2.5V

PVDD = 3.6V

PVDD = 5V

Figure 9. THD + N vs. Output Power into 4 Ω, Gain = 5 V, fS = 128×
