11
LT6210/LT6211
62101f
TIME (10ns/DIV)
TIME (10ns/DIV)
TIME (100ns/DIV)
TIME (10ns/DIV)
TIME (10ns/DIV)
TIME (100ns/DIV)
VS = ±5V
VIN = ±25mV
RF = RG = 887Ω
RSET = 20k TO GND
RL = 150Ω
VS = ±5V
VIN = ±25mV
RF = RG = 1.1k
RSET = 56k TO GND
RL = 150Ω
VS = ±5V
VIN = ±25mV
RF = RG = 11k
RSET = 1M TO GND
RL = 1k
VS = ±5V
VIN = ±1.75V
RF = RG = 887Ω
RSET = 20k TO GND
RL = 150Ω
VS = ±5V
VIN = ±1.75V
RF = RG = 1.1k
RSET = 56k TO GND
RL = 150Ω
VS = ±5V
VIN = ±1.75V
RF = RG = 11k
RSET = 1M TO GND
RL = 1k
62101 G33
62101 G34
62101 G35
62101 G36
62101 G37
62101 G38
62101 G39
SUPPLY CURRENT PER AMPLIFIER (mA)
0.1
1
10
100
1000
110
AV = 2
VOUT = 100mVP-P
TA = 25°C
VS = ±1.5V
VS = ±5V
SUPPLY CURRENT PER AMPLIFIER (mA)
0.1
0
200
400
600
800
110
62101 G32
1000
100
300
500
700
900
VS = ±5V
AV = 2
VOUT = 7VP-P
TA = 25°C
RISING
EDGE RATE
FALLING
EDGE RATE
SUPPLY CURRENT PER AMPLIFIER (mA)
–30
–40
–50
HD2
HD3
62101 G31
–80
–60
–70
10
0.1
1
VS = ±5V
AV = 2
VOUT = 2VP-P
TA = 25°C
Small-Signal Transient Response
(IS = 6mA per Amplifier)
Small-Signal Transient Response
(IS = 3mA per Amplifier)
Small-Signal Transient Response
(IS = 300µA per Amplifier)
Large-Signal Transient Response
(IS = 6mA per Amplifier)
Large-Signal Transient Response
(IS = 3mA per Amplifier)
Large-Signal Transient Response
(IS = 300µA per Amplifier)
1MHz 2nd and 3rd Harmonic
Distortion vs Supply Current
Slew Rate vs Supply Current
–3dB Small-Signal Bandwidth
vs Supply Current
TYPICAL PERFOR A CE CHARACTERISTICS (Supply Current Is Measured Per Amplifier)
