General Description
The COMLINEAR CLC2058 is a dual voltage feedback amplifer that is internally frequency compensated to provide unity gain stability. The CLC2058 offers 3.5MHz of bandwidth at a gain of 2. The CLC2058 also features high gain, low input voltage noise, high input resistance, and superb channel separation making it well suited for audio flter applications in set-top-boxes, DVD players, and televisions.

FEATURES
■  Unity gain stable
■  100dB voltage gain
■  5.5MHz gain bandwidth product
■  0.5MΩ input resistance
■  100dB power supply rejection ratio
■  95dB common mode rejection ratio
■  4V to 36V single supply voltage range
■  ±2V to ±18V dual supply voltage range
■  Gain and phase match between amps
■  CLC2058: improved replacement for NJM4558 and MC1458
■  CLC2058: Pb-free SOIC-8

APPLICATIONS
■  Active Filters
■  Audio Amplifers
■  Audio AC-3 Decoder Systems
■  General purpose dual ampliifer
