2 / 3 page

www.roithner-laser.com

Outline Dimensions

all dimensions in mm

Electrical Connection

(IEC 60130-10, Type A, 5.5/2.1 mm)

Precautions

Static Electricity:

Precautions against electrostatic discharge (ESD) must be taken when handling or operating the module. Surge

voltage or electrostatic discharge can result in complete failure of the laser diode.

Heat Sinking:

In order to maintain lifetime and stability of the laser diode it is essential to provide efficient heat management. For long

time stable operation proper contact between laser module and heat sink is mandatory.

Safety:

This laser module emits highly concentrated visible light which can be hazardous to the human eye and skin. It is

classified as CLASS 2 laser product according to IEC 60825-1 and 21 CFR Part 1040.10 Safety Standards. Actual

laser light emitted and precautions necessary strongly depend on mode of operation.

31.3±0.5

20.0

~ 300

+ VDC

GND
