 39 / 43 page
background image
Revision 1.3
Mar.22 2001
-38-
GL646USB
111:128 steps deceleration
B4~0:STOPTIM[4:0]:select acceleration/deceleration stop time.
The unit is LPERIOD.
7.69. Reg :70H
(Write)
GPI[12:7]
: GPIO12~7 input ports.
7.70. Reg :71H
(Write)
GPI[6:1]
:GPIO6~1 input status.
7.71. Shading mapping(Chunky)
Attribute
Resolution
A[18:0]
600dpi
(RGB Chunky)
00000H~07FFFH
SIZE : 32k
1200dpi
(RGB Chunky)
00000H~0FFFFH
SIZE : 64k
Shading Mapping
2400dpi
(RGB Chunky)
00000H~1F7FFH
SIZE : 126k
7.72. Shading mapping(Planer)
7.73. Gamma mapping
Attribute
Color
A[18:0]
RED
09000H~09FFFH
SIZE : 4K
Attribute
Resolution
A[18:0]
R
LINE
00000H~029FFH
G
LINE
02A00H~053FFH
600dpi
(RGB Planer)
B
LINE
05400H~07DFFH
R
LINE
00000H~054FFH
G
LINE
05500H~0A9FFH
1200dpi
(RGB Planer)
B
LINE
0AA00H~0FEFFH
R
LINE
00000H~0A7FFH
G
LINE
0A800H~14FFFH
Shading Mapping
2400dpi
(RGB Planer)
B
LINE
15000H~1F7FFH
