Series UB2

Low Profile Pushbuttons

D93

www.nkkswitches.com

Distinctive Characteristics

Wide selection of illumination effects is achieved with single and bicolor,

1- or 6-element LEDs in flat, beveled, or sculptured caps.

Alternating legends in choice of sculptured or flat caps, combined

with super bright bicolor LED.

Combination of PCB mountability and short body

allows use in compact applications.

Small behind panel dimension for snap-in mounting

in tight spaces.

Snap-acting contact mechanism provides sensitive

actuation with audible feedback; quick-make,

quick-break characteristic limits arcing and

prolongs electrical life.

Latchdown mechanism, independent of switching

mechanism, gives outstanding stability and

reliability plus visible and tactile indication of

circuit status.

Terminals are epoxy sealed to lock out flux, solvents,

and other contaminants.

Momentary and alternate action circuits available in the same

space-saving body size.

Matching indicators available.

Actual Size
