T48C862-R4 [Preliminary]

4551C–4BMCU–01/04

UHF ASK/FSK Transmitter Block

Features

• Integrated PLL Loop Filter

• ESD Protection (4 kV HBM/200 V MM, Except Pin 2: 4 kV HBM/100 V MM) also at ANT1/ANT2

• Maximum Output Power (10 dBm) with Low Supply Current (9.5 mA Typically)

• Modulation Scheme ASK/FSK

– FSK Modulation is Achieved by Connecting an Additional Capacitor between the XTAL Load Capacitor and the Open-

drain Output of the Modulating Microcontroller

• Easy to Design-in Due to Excellent Isolation of the PLL from the PA and Power Supply

• Supply Voltage 2.0 V to 4.0 V in the Temperature Range of -40

° C to +125° C

• Single-ended Antenna Output with High Efficient Power Amplifier

• External CLK Output for Clocking the Microcontroller

• 125

° C Operation for Tire Pressure Systems

Description

The PLL transmitter block has been developed for the demands of RF low-cost transmission systems, at data rates up to

32 kbaud. The transmitting frequency range is 429 MHz to 439 MHz. It can be used in both FSK and ASK systems.
