This is information on a product in full production.

April 2017

DocID028319 Rev 2

1/55

STUSB1602

USB Type-C™ controller with TX/RX line driver and BMC

Datasheet

- production data

Features

• Type-C™ attach and cable orientation

detection

• Power role support: source/sink/DRP

• Configurable start-up profiles

• Integrated power switch for VCONN supply:

– programmable current limit up to 600 mA

– overcurrent, overvoltage, and thermal

protection

– under-voltage lockout

• I2C interface and interrupt

• Integrated VBUS voltage monitoring

• Integrated VBUS and VCONN discharge path

• Integrated BMC transceiver

• VBUS switch gate driver

• Low power standby mode

• Dead battery mode support

• Short-to-VBUS protection on CC pins (22 V) and

VBUS pins (28 V)

• Accessory mode support

• Dual power supply (VSYS and/or VDD):

–VSYS = [3.0 V; 5.5 V]

–VDD = [4.1 V; 22 V]

• Compliant with:

– USB Type-C™ rev 1.2

– USB PD rev 2.0 (Certif. test ID 1010032)

• Compatible with:

– USB PD rev 3.0

Applications

•

Smart plugs, wall adapters, and chargers

•

Power hubs and docking stations

•

Smartphones and tablets

•

Gaming and PNDs

•

Displays

•

Cameras, camcorders, and MP3 players

•

Any Type-C source or sink device

Description

The STUSB1602 is a generic IC designed in a

20 V technology. It addresses USB Type-C™ port

management both on the host and/or device side,

and is suited for a broad range of applications.

The STUSB1602 can handle all functions from

Type-C attach detection, plug orientation

detection, host to device connection, VCONN

support, and VBUS configuration.

It also provides a USB PD TX/RX line driver and

BMC (biphase mark coding) transceiver which

allows USB PD negotiation and alternative mode

through an external MCU.

Additionally, the STUSB1602 provides support for

dead battery operation.

Table 1. Device summary table

Order code

Description

Package

Marking

Temperature range

STUSB1602QTR

USB Type-C™ controller

with TX/RX line driver and BMC

QFN24 EP 4x4 mm

1602

-40 °C up to 105 °C

www.st.com
