CC1150-RTY1 datasheet(17/67 Pages) TI1

17 / 67 page

DATA

byte 0

ADDR

FIFO

DATA

byte 1

DATA

byte 2

DATA

byte n-1 DATAbyte n

...

ADDR

strobe

DATA

ADDR

strobe

ADDRreg

ADDR

reg n

DATAn

DATAn+1

DATAn+2

...

ADDR

strobe

...

CSn:

Command strobe(s):

Read or write register(s):

Read or write consecutive registers (burst):

DATA

ADDR

reg

DATA

ADDR

reg

...

DATA

byte 0

ADDR

FIFO

DATA

byte 1

Combinations:

DATA

ADDR

reg

DATA

ADDR

reg

ADDR

strobe

ADDR

strobe

...

Read or write n+1 bytes from/to RF FIFO:

CC1150

www.ti.com

SWRS037B – JANUARY 2006 – REVISED MARCH 2015

Figure 5-6. Register Access Types

5.5.6

PATABLE Access

The 0x3E address is used to access the PATABLE, which is used for selecting PA power control settings.

The SPI expects up to eight data bytes after receiving the address. By programming the PATABLE,

controlled PA power ramp-up and ramp-down can be achieved, as well as ASK modulation shaping for

reduced bandwidth.

NOTE

The ASK modulation shaping is limited to output powers below –1 dBm. See SmartRF Studio

[11] for recommended shaping sequence.

See also Section 5.16 for details on output-power programming.

The PATABLE is an 8-byte table that defines the PA control settings to use for each of the eight PA power

values (selected by the 3-bit value FREND0.PA_POWER). The table is written and read from the lowest

setting (0) to the highest (7), one byte at a time. An index counter is used to control the access to the

table. This counter is incremented each time a byte is read or written to the table, and set to the lowest

index when CSn is high. When the highest value is reached the counter restarts at zero.

The access to the PATABLE is either single byte or burst access depending on the burst bit. When using

burst access the index counter will count up; when reaching 7 the counter will restart at 0. The read/write

bit controls whether the access is a write access (R/W=0) or a read access (R/W=1).

If one byte is written to the PATABLE and this value is to be read out then CSn must be set high before

the read access in order to set the index counter back to zero.

NOTE

The content of the PATABLE is lost when entering the SLEEP state. For more information,

see DN501 [8].

5.6

Microcontroller Interface and Pin Configuration

In a typical system, CC1150 will interface to a microcontroller. This microcontroller must be able to do the

following:

•

Program CC1150 into different modes

•

Write buffered data

•

Read back status information via the 4-wire SPI-bus configuration interface (SI, SO, SCLK and CSn)

5.6.1

Configuration Interface

The microcontroller uses four I/O pins for the SPI configuration interface (SI, SO, SCLK and CSn). The

SPI is described in Section 5.5.

Detailed Description

Submit Documentation Feedback

Product Folder Links: CC1150
