1. Introduction

The PCB.SMAFST.2H.A.HT connector was designed to be mounted on a PCB, it has a Solder Post

for connection and 2 Mounting holes. The connector pin is directly soldered onto pads on the PCB.

The connector is a standard SMA (F) Jack. The SMA connector is the most popular type

connector for RF applications. Taoglas connectors are all RoHS compliant.

2. Specification

ELECTRICAL

Impedance

50Ω

Frequency Range

0~12.4 GHz

Working Voltage

Max. 335 Vrms

Dielectric withstanding Voltage

≤1000 Vrms

Insulation Resistance

≥5000M Ω

MECHANICAL

Connector Dimension

11.52 X 15.88 mm

Connector Pin Diameter

1.27 mm

Connector Pin Height

2 mm

Connector Type

SMA (F)

ENVIRONMENTAL

RoHS compliant

Operating Temperature

-40°C to +85°C
