1. Introduction

The PCB.MMCXFSTJ.HT connector was designed to be mounted on a PCB. The maximum

thickness of PCB that the connector can be used with is 2.5mm. The connector pin is directly

soldered onto pads on the PCB. The connector is a standard MMCX (F) Jack. Taoglas connectors

are all RoHS compliant.

2. Specification

ELECTRICAL

Impedance

50Ω

Frequency Range

DC~6 GHz

Working Voltage

Max. ≤170 Vrms

Dielectric withstanding Voltage

500 Vrms

Insulation Resistance

≥1000M MΩ

MECHANICAL

Connector Dimension

7.5mm*3.5mm

Max. Thickness PCB acceptable

2.5mm

Connector Pin Diameter

0.7 mm

Connector Type

MMCX(F) Vertical PCB Thru Hole Jack

ENVIRONMENTAL

RoHS compliant

Operating Temperature

-40°C to +85°C
