Technical Data Sheet

PROTECTION CAP

170-XXX-XXXXX

Rosenberger Hochfrequenztechnik GmbH & Co. KG

P.O.Box 1260

D-84526 Tittmoning

Germany

www.rosenberger.de

Tel.

: +49 8684 18-0

Email : info@rosenberger.de

Page

2 / 2

170-089-00000

2,36x4,76x0,71

black

Mini Coax (f + m)

170-097-00000

26,99x12,70x1,52

black

HVR40 Kabelseite

170-097-00001

38,1x19,05x1,39

black

HVR40 Stiftwanne

170-109-00000

34,93x19,05 x 1,65

black

SLPCC001-C05

170-110-00000

44,45x19,05x1,65

black

SLPCC001-C06

170-111-00000

53,98x19,05x1,65

black

SLPCC001-C07

170-115-00000

31,75x20,0x1,65

black

H1S101-92SPC0B1-A

170-116-00000

17,45x19,05x1,52

black

M&I

170-127-00000

3,48x6x0,71

black

SMB (f)

Material and plating

Parts

Material

Plating

Protection cap

PVC Shore A 65±5

Environmental data

Temperature range

-45°C to +85°C

RoHS

compliant

Draft

Date

Approved

Date

Rev.

Engineering change number

Name

Date

F. Fraunhofer

22.01.09

B. Huppenberger

11.01.17

h00

17-0004

P. Schiebeck

11.01.17

While the information has been carefully compiled to the best of our knowledge, nothing is intended as representation or warranty on

our part and no statement herein shall be construed as recommendation to infringe existing patents. In the effort to improve our

products, we reserve the right to make changes judged to be necessary.
